MoxiE Flat Wire Ultra High Performance Power Inductors MOX-HPC-6630 SERIES 6.65mm x 6.45mm x 3.00mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 0.18uH~3.30uH Isat Max: 39.00 Amps MOX-HPC-8878 SERIES 8.80mm x 8.30mm x 7.80mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 0.68uH~10.00uH Isat Max: 38.00 Amps MOX-HPC-1188 SERIES 11.6mm x 10.5mm x 8.80mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 2.20uH~15.00uH Isat Max: 32.00 Amps MOX-HPC-1610 SERIES 16.4mm x 15.4mm x 10.0mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 4.70uH~22.00uH Isat Max: 47.00 Amps MOX-HCPI-2623 SERIES 26.9mm x 16.9mm x 23.2mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 3.30uH~33.0uH Isat Max: 105.00 Amps MOX-HCPI-2014 SERIES 20.5mm x 14.0mm x 12.0mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 0.50uH~33.00uH Isat Max: 75.00 Amps MOX-HCPI-2015 SERIES 20.5mm x 14.0mm x 14.5mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 2.20uH~33.00uH Isat Max: 60.50Amps MOX-HCPI-2815 SERIES 27.9mm x 19.7mm x 15.4mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 1.50uH~33.00uH Isat Max: 100.00 Amps
COILCRAFT XAL6030, COILCRAFT XAL6060, COILCRAFT XAL8080,COILCRAFT XAL1060, COILCRAFT XAL1010, COILCRAFT XAL1510, COILCRAFT XAL more info more info
MoxiE Custom Designs Available
MOX-HCPI-2818 SERIES 27.9mm x 19.7mm x 17.8mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 3.30uH~33.00uH Isat Max: 92.50 Amps DONíT SEE WHAT YOUR LOOKING FOR?   WE HAVE CUSTOM MOXIE DESIGNS! MoxiE offers custom designs on all of our magnetic component products to meet your individual project requirements.  From custom inductance values, to complete custom packages, MoxiE has the expertise to meet your specific design without compromise. Our design team can provide you custom specifications in days not weeks and our quick-turn production on samples and prototypes is the quickest in the industry.  Thatís MoxiE.
